SKU: EZ-PDXN/5C16BK:TRI

5c16mm Flexible Rubber RE-110 0.6/1kv 110deg AS/NZS5000PACW BR,BL,BK,WH,EA

Tricab 5 Core Flexible Cable

Login for price

EZ-PDXN/5C16BK:TRI.jpg

5c16mm Flexible Rubber RE-110 0.6/1kv 110deg AS/NZS5000PACW BR,BL,BK,WH,EA

Attributes
Conductor	16mm² Fine wire plain or tinned annealed copper
Cores	5 - White (numbered) plus 1 Green/Yellow Earth
Insulation	LSFLEX® R-70 (X-HF-110), Cross-Linked, Thermoset, Elastomeric, and individually numbered
Jacket	Low Friction E-RUBBER® S-20 Thermoplastic, Elastomeric, Flame Retardant, Splash resistant to oil, skydrol, petrol, acid and sea water. Resists ozone and UV. Excellent abrasion resistance. Submersible to 500m. Best Practice PVC.
Installed Temp Rating	-40°C to +110°C
Rated Voltage	600/1000 Volts
Min. Bend Radius	76mm
Nominal O.D (mm)	25.2mm
Current Rating	106 amp
Earth Size	16mm²
Separator	Polypropylene tape

Data Sheet

Download
